Track Adjuster Assy – KOMATSU – D61PX-23/24 (134-30-73161/134-30-63154/134-30-63142)

NAME Track Adjuster Assy
BRAND KOMATSU
MODEL D61PX-24
PART NUMBER 134-30-73161 (Spring)
134-30-63154(Cylinder)
134-30-63142 (Piston)
13Y-30-15312 (Yoke)
OTHER MODEL D61PX-23; D61PX-24



As a product which is completely designed and produced according to GENUINE criteria and specification. MERA offers to market the Track Adjuster Assy – KOMATSU – D61PX-23/24 (134-30-73161/134-30-63154/134-30-63142) with excellent performances, high durability and optimum shock absorbance for your mining and construction equipment anywhere and any conditions.

Especially, MERA is doing the research and development for our Track Adjuster Assy. By the calculation of tension strength and safety factors, we improve it from the bases of genuine item (increase Rod diameter, increase hardness by heat-treatment, hard chrome plating and improve surface finish on cylinders). All of this allows our product deliver the higher performance compare to what others can do. All the steel materials are imported from Japan and other OEM components suppliers (Recoil Springs, Grease Valves, seal kits …), plus the advanced machinery allow us create the product with highest precision and incredible tolerance compare to genuine parts

Component Items Qty
  01010-80830   BOLT [4]
  01643-30823   WASHER [4]
  04077-00090   RING [2]
  07020-00900   FITTING, GREASE [2]
  07177-07530   BUSHING [4]
  14X-30-13310   NUT [2]
  14X-30-13241   SPACER [4]
  134-30-73161   SPRING [2]
  134-30-63154   CYLINDER [2]
  17M-50-24360   SEAL [2]
  134-30-63181   SPACER [2]
  134-30-63210   CABIN, RECOIL SPRING [2]
  203-30-42260   VALVE [2]
  14X-30-13174   PLATE [2]
  07177-08030   BUSHING [2]
  195-50-22860   SEAL [2]
  134-30-63220   HOLDER [2]
  01010-81235   BOLT [8]
  01643-31232   WASHER [8]
  04064-04518   RING, SNAP [2]
  07155-00720   RING, WEAR [4]
  09370-00070   U-PACKING [2]
  13Y-30-15312   YOKE [2]
  134-30-63142   PISTON [2]
  154-30-11540   LOCK [2]
  154-30-11332   WASHER [2]
  01010-82055   BOLT [2]
  01010-81660   BOLT [12]
  01643-31645   WASHER [12]
